12 Core ADSS Fiber 120m Span Single Mode Fiber

Short Description:

ADSS Fiber in 12 Core apply to aerial overhead selfsupporting installation for LV MV Power line or exsiting pole as feeder cable

The Work Tension load is 2500N ,stronger strength idea for the asdss fiber span up to 120meter

Hunan jiahome adss fiber take kelvar raw material & design accroding to IEC60794,based on Fiber strain ≤0.33% the fiber loss is no any change

Good quality ,no the accident of cable broken

Cable Diameter :10.4mm Anti UV Proection PE Outer sheath

Fiber type: single mode fiber G652D

Cable fiber attenuation: ≤0.36dB/km@1330nm ≤0.22dB/km1550nm

Brand: HunanJiahome or OEM your brand print on cable and package

Delivery: FOB any port China or CIF (we Ship goods to your destination port )

Delivery time: 2Weeks after payment

Payment terms: T/T Letter of Credit , D/P etc Flexible terms

Warranty: 25years

Price: Very competitive price ,discount negotiation now

We are ISO IEC certificated Chinese manufacturer ,confidence with good quality ,we are ready !and you ?Click send inquiry to get best offer and free sample !

Send email to us

Product Detail

Product Tags

Video

Structure

Dry core water swellable tape and water block yarn wrap the cable core Longitudinal moisture-proof

6Fiber in a buffer tube .2buffer tube and 4 filler element strands around the central strength member (CSM) FRP

Take the kelvar for peripheral strength member assure the tension load MAT up to 2500N Meet 120m Span aerial isntallation

Two ripcords under outer sheath for strip cable easy

Hunan Jiahome is the leading manufacturer of adss fiber cable ,

We used the good material to produce good quality adss fiber optic.

The design of allowable tension is 2500N better than others 1800N or 2100N.Suitable for harsh installation situation ! Contact at us now to get detail specification and best offer.

Application

Energy Power :ADSS Fiber aerial install for Power Electric utility as singal distribution line like smart grid

Also as approach cable for power substation because of its all dielectric features

Telecommunication : Used for the backbone cable for backbone network like city -city city to village

Only 12 Core adss fiber also apply for the distribution network line ,like fiber to the home

For more applycation please contact at hunan jiahome

CABLE DESIGN

Part code	ADSS fiber 12-120m span
Number of Fibers	Unit	12core
Number of fiber in tube	Nos	6
Number of loose tube	Nos	2
Number of dummy filler	Nos	4
Central strength member	Material	FRP
Loose tube	Material	PBT
peripheral strength member	Material	Aramid yarn
Water block	Material	Water swellable tape and water block yarn
Outer sheath	Material	HDPE
Cable nominal Diameter	MM ±0.2	10.4
Cable nominal weight	Kg/Km ±5	85
Max. Allowable tension Load	N	2500
Span		Suitable for 120 span
Max. crush resistance	N	2000 (Short term) / 1000 (Long term)
Min. bending radius		At full load 20 x Cable OD (including poles) At no load 15 x Cable OD
Temperature range		Installation -0 -> +50 Operation -10 -> +70
