GYFTC8Y 4 Core Dielectric Fiber Optic Cable Specification

Short Description:

The optical fiber is 250µm, the loose tube is made of high modulus plastic, which is filled with waterproof compound. The center of the cable core is a metal reinforced core, Tubes (and fillers) are stranded around the strength member into a compact and round cable core, which is filled with the waterproofing compound to protect it from water ingress. Plastic coated aluminum tape or steel tape is longitudinally wrapped and extruded into a polyethylene sheath to form a cable.With self-supporting messenger wire.

100% ISO IEC Certificated Manufacturer ,Help You Save Purchase Cost ! Click send inquiry to get best offer and free sample now !

Send email to us

Product Detail

Product Tags

Video

Application

Central Strength member :FPR

Loose tube Tube: SZ strands multi tube In PBT material

Water block:Gelly filling compound in tube and Cable Core

Reinforcing: High modulus Aramid yarn

Sheath: UV stabilised Polyethylene in (PE)

Messenger wire :High strength Fiber reinforce glass (FRP)

Features

1. Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property

2. Two parallel strength members ensure good performance of crush resistance to protect the fiber

3.Simple structure, light weight and high practicability

4. Novel flute design, easily strip and splice, simplify the installation and maintenance

5. Low smoke, zero halogen and flame retardant sheath

6. Simple structure, light weight and high practicability

Technical data sheet

Part code	JH-GYFTC8Y
Number of Fibers	Unit	4	8	12	24
Number of fiber in tube	Nos	4	4	4	6
Number of loose tube	Nos	1	2	3	4
Number of filler Rope	Nos	5	3	2	1
Central strength member	Material	FRP	FRP	FRP	FRP
Loose tube	Material	PBT
	Diameter ±0.06mm	1.7
	Thickness ±0.03mm	0.32
Filler rope	Material	LDPE
	Diameter ±0.06mm	1.7
	Color	White
Water block	Material	Gelly filling compound in tube and Cable Core
Support Piece	Material	FPR
	Diameter	3.0mm
Web	Size	2.0*2.0mm
	Material	MDPE
Outer sheath 1	Material	MDPE
	Thickness ±0.2 mm	1.2
Outer sheath 2	Material	MDPE
	Thickness ±0.2 mm	1.7
Cable nominal Diameter	±0.5mm	8.7×16.2
Cable nominal weight	Kg/Km ±10	115
Allowable Tensile Strength	N	Long term :1000N Short terms:2700N
Max. crush resistance	N	Long term :1100N (/100mm) Short terms:2200N(/100mm)
Bending radius		At full load 20 x Cable OD (including poles) At no load 10 x Cable OD
Temperature range		Installation -20> +60 Transport & Storage-40 -> +70 Operation -40 -> +70

SINGLE MODE G652D

Mode Field Diameter @ 1310 nm		8.7-9.5 mum
Mode Field Diameter @ 1550 nm		9.8-10.8mum
Cladding diameter		125.0 ±± 0.7mm
Core/cladding concentricity error		0.6 um
Cladding non-circularity		1.0 %
Refractive index profile		Step
Design		Matched cladding
Primary coating material		UV curable acrylate
Primary coating Diameter		235-250um
Attenuation	@ 1310nm	£ 0.36 dB/km (cabling)
	@ 1383±3nm	£ 0.34 dB/km
	@ 1550nm	£ 0.22dB/km (cabling)
Dispersion	@ 1288 ~ 1339nm	£ 3.5 ps/nm×km
	@ 1550nm	£ 18 ps/nm×km

Zero dispersion wavelength		1300 – 1324 nm
Dispersion slope at zero dispersion wavelength		£ 0.092 ps/nm²×km
Cabled cut-off wavelength (lcc)		£ 1260 nm
Polarization mode dispersion link value		£ 0.2 ps/√_km
Mechanical Characteristics
Proof stress level		≥0.69 GPa
The loss increase of 100 turns of fiber loosely wound with		£0.05dB (at 1550nm)
25mm radius
Effective group index of refraction Neff		1.466(at 1310nm)
Effective group index of refraction Neff		1.467 (at 1550nm)
